Description
Technical Specifications
| PARAMETER | SPECIFICATION |
| Displaying mode | B, B/B,4B, B/M, M, B/C, B/C/D, B/D, duplex, triplex, CFM, PW |
| Signal processing | Full-digital beam forming, dynamic filter, dynamic real time receiving
focusing, spectral processing, CFM processing, real-time dynamic focusing, dynamic aperture in all fields |
| Image processing | THI
Storage: 16G Power adjustable Smoothing function Edge enhancement One-key optimization Image conversion Wall filter adjustable Base line adjustable PRF adjustable AIO-Auto image optimization IZoom: Instant full screen image I-Image: intelligent optimization MBF: Multi Beam Former SA: Synthetic Aperture Ultrasonic imaging Iclear: Speckle Noise Reduction CDF: Contunuous Dynamic Focusing |
| General measurement | Normal, MSK, ABD, OB, Pelvic,Urology, Cardiac, Small Parts, Vascular |
| Normal
measurement |
Volume, V3L, STD_S, Area Trace,Mtime, MHR, D Time, DV, D Common, D Auto, Area, Angle, CrossLine, STD D, ParalleLine, Mdist,MV, D HR, DA, D Trace |
| ABD packages | ABD, Aorta, R_Kidney & L_Kidney, Bladder, Prostate |
| OB Packages | Early OB, Rt-Ovary, Lt-Ovary, Uterus, Fetal_Biome, Long_Bones, AFI |
| Pelvic Packages | Uterus, Rt/Lt – Ovary, Rt/Lt-Follicle |
| Urology packages | Rt/Lt- kidney measurement, Bladder, Prostate,Rt/Lt_Testicle |
| Small Parts | Rt/Lt_Thyroid, Rt/Lt_Testicle, Vessel, Breast |
| Vascular | Stenosis D, senosis A, Intima, Arterial, Venous |
| MSK | Distance, Area, Hip_Angle |
| Scanning depth | ≥250mm |
| Probe elements | 80 |
| Cine loop | Automatically & manually |
| Image storage
format |
BMP, JPEG, PNG, DICOM(Option) |
| Input/output ports | Video Port, S-Video Port, Remote Port, LAN1/2 Port, VGA |
| Standard
Configuration |
Main unit, LED monitor, 3.5Mhz convex probe, 2 Probe connectors, User’s
Manual, hard disk (SSD), battery |
| Options | 7.5Mhz linear probe, 6.5Mhz Transvaginal Probe, Trolley, Printers, Biopsy
kit，Aluminum case |
